CENG 242

Hw #1

Spring 2007/2008

(Due: March 16th, 2008 Sunday 23:59)



You are given a list of binary trees. All the nodes of trees are numbered with an integer. You can merge two trees if the root of one has the same number with one of the leafs of the other. A sample figure is given below.





You can merge Tree 1 and Tree 2 and get Merged Tree as shown in the figure. You should write a Haskell code merging the given list of trees. The tree is defined as follows:



data Tree = Empty | Branch Integer Tree Tree



You will write a function mergeTrees in the form:



mergeTrees::[Tree]->Tree



Constraints:



·        A number will appear at most twice in the given list of trees and a number will appear at most once in a tree.

·        If there are more than one solutions, both will be considered OK.

·        If all of the trees in the given list can be merged to a single tree, you should give the merged tree as a result. Otherwise, you should return Empty.

·        All the trees in the list will be nonempty.



Examples:



·         mergeTrees [Branch 8 (Branch 12 (Branch 43 Empty Empty) (Branch 24 Empty Empty)) (Branch 55 Empty (Branch 6 Empty Empty)), Branch 24 (Branch 15 Empty Empty) (Branch 22 (Branch 17 Empty Empty) Empty)]



This is the example given in the figure and the result is:



(Branch 8 (Branch 12 (Branch 43 Empty Empty) (Branch 24 (Branch 15 Empty Empty) (Branch 22 (Branch 17 Empty Empty) Empty))) (Branch 55 Empty (Branch 6 Empty Empty)))



·         mergeTrees [Branch 6 (Branch 7 Empty Empty) Empty, Branch 5 (Branch 6 Empty Empty) Empty, Branch 7 Empty (Branch 8 Empty Empty)]



(Branch 5 (Branch 6 (Branch 7 Empty (Branch 8 Empty Empty)) Empty) Empty)



·         mergeTrees [Branch 5 Empty (Branch 10 Empty Empty), Branch 9 (Branch 3 Empty Empty) (Branch 5 (Branch 8 Empty Empty) Empty), Branch 10 Empty (Branch 33 Empty Empty)]



You can merge first and third trees but second tree can not be merged with any other. So the result is:



Empty





Specifications:



·        All the work should be done individually.

·        Your codes should be written in Haskell and have the name “Hw1.hs”.

·        Your code should have the module Hw1 (i.e. your code should start with: module Hw1 where)

·        In evaluation, black box method will be used. So, be careful about names of functions, data structures etc.

·        You will submit your codes through cow system.

·        You should test your codes in inek machines with hugs before submitting.\







Note:



You can not view a Tree in interpreter if you do not implement a show function for it. So use this function in order to see your trees:



showTree :: Tree -> String

showTree Empty = "Empty"

showTree (Branch x left right) = "(Branch " ++ show x ++ " " ++ showTree left ++ " " ++ showTree right ++ ")"
